| Panel Color |
Aluminum Black |
| Power Input Conditions |
AC190-250V, 50-60Hz, single phase 3-wire (Line, Neutral, Earth) |
| Channel Quantity |
8-channel multi socket relay controlled + 2-way universal socket direct output |
| Relay Output Power |
Single channel: 6000W / Tổng cộng: 7000W (maximum withstand reactive power) |
| Output Power Socket Specification |
ABS chống cháy, lõi đồng phốt pho, chịu dòng tối đa 16A, universal socket |
| Function Features |
1. Dot matrix function display
2. LCD voltmeter
3. Password setting startup
4. Sequential opening & reverse closing, cài đặt kênh tùy chọn
5. Adjustable time interval
6. Free channel shutdown
7. Panel channel independent control |
| Interval/Timing Time |
Mặc định 1 giây (có thể tùy chỉnh) |
| Relay Contact Current |
30A 277VAC |
| Circuit Board |
Double-sided fiberboard, dây nguồn chính tăng độ dày gấp đôi |
| Power Supply |
Built-in switching power supply, AC90-260V 50-60Hz |
| Main Cable |
3 x 4mm², dài 1.5m, phích cắm chuẩn Châu Âu |
| Switch Type |
Push button touch switch |
| Independent Channel Switch |
Hỗ trợ điều khiển riêng từng kênh trên panel |
| Voltmeter Display |
Dot matrix voltmeter + function menu |
| External Switch |
Có |
| Power Purification (EMI Filter) |
None |
| Body Size |
482mm (L) × 185mm (W) × 44mm (H) – non-standard 1U |
| Single Package Size |
555mm × 255mm × 85mm (thùng giấy Meiniu), Gross Weight: 3.5KG |
| Outer Package (5 Sets) |
445mm × 270mm × 570mm, Tổng trọng lượng: 18KG |
